LRI-AAST: L4 laboratory: Aeroelastics Laboratory

Lab Equipment Application
L4 PULSE FFT - analyser of dynamic response

Equipment is suitable for ground frequency tests of aircrafts, especially flutter analysis and modal properties of wings and fuselage.

Located at CTU FME laboratory at Karlovo namesti 13, Prague 2.

ACCELEROMETER - piezoelectric acceleration sensor
DYNAMOMETER - piezoelectric force sensor
DRIVERS - energizing electromagnetic vibratory exciter for exciting construction
RECOVERY BAGS to release the aircraft from the base frame
3D LASER SCANNER to monitor strain and stress fields of dynamically loaded 3D complex structured

Contactless vibration measurement can be used for measuring small objects, hot surfaces, inaccessible parts or for measuring in a radioactive and "high-voltage" environment. It can also be successfully used in the field of acoustics, elastoacoustics, and electroacoustics.

Located at CTU FME laboratory in Prague 6 – Dejvice.

album/Album_Model_Album/1359/image4.jpegEquipment is suitable for ground frequency tests of aircrafts:

  • PULSE FFT analyser of dynamic response
  • ACCELEROMETER piezoelectric acceleration sensor (14g, 71g, 500g, single-axis, three-axis)
  • DYNAMOMETER piezoelectric force sensor (1000 N)
  • DRIVERS Energizing electromagnetic vibratory driver for driving construction (0.1Hz to 1kHz)
  • RECOVERY BAGS to release the aircraft from the base frame (3pc)

3D LASER SCANNER

to monitor strain and stress fields of dynamically loaded 3D complex structured - Contactless vibration measurement can be used for measuring small objects, hot surfaces, inaccessible parts or for measuring in a radioactive and "high-voltage" environment. It can also be successfully used in the field of acoustics and electroacoustics.

album/Album_Model_Album/1359/image11.jpegalbum/Album_Model_Album/1359/image12.jpeg




Photogallery LRI-AAST: L4

Download the information brochure
